The CASE 850M Compact Crawler Tractor is the ideal solution for various challenges. With its reduced size, it adapts and delivers efficiency in various situations.
The compact crawler tractor is designed for versatility in different soil types, including mud, offering traction and stability. Its tracks reduce soil compaction and minimize impacts on sensitive terrains like wet, clayey, or sandy soils.
Hydrostatic two-way transmission with infinitely variable control via a single lever with direct electronic monitoring, power-turn connection, and counter-rotation
Final transmission:
Triple reduction; helical gear/planetary decelerator with hydrostatic drive delay
Parking brake with hydraulic release applied by spring
15 incremental speed configurations and adjustable forward/reverse speed differential settings
Settings according to operator preference for maximum speed, shuttle sensitivity, and steering sensitivity
Decelerator with selectable engine deceleration or transmission braking mode
Variable pitch from 52° – 60° with integral adjustment tool
Electro-hydraulic single-lever control for blade lifting, angling, and tilting
Hydraulic track adjusters
Easy-to-clean track covers
Sealed and lubricated track chain (SALT)
Tracks and lower rollers with permanent lubrication
Track adjuster protector
Track guides – front and rear
Shock-resistant pulley installation
HD track covers
Track frame, sprocket, and mounting supports with high strength
High-visibility track pulley
Reverse alarm
Horn
Premium LED work light package:
4 on the front
2 on the rear
Master disconnect switch
Turbo pre-cleaner
Front tow hook
Ripper
Environmental drain
4-coil electro-hydraulic valve with connectors for field-installed ripper
Anti-vandalism package
Rear transmission protector
Rearview mirror (cab models only)
Operator manual compartment
Diagnostic check doors
Two additional power sources available for heater, pneumatic seat, or extra 12-volt port
CASE 4G SiteWatch™ telematics – includes hardware and a 2-year advanced subscription
