Wheel Loaders - 621E

Material handling requires machines with excellent traction, great power, high lifting capacity, quiet operation, and low fuel consumption.

CASE went further and designed the 621E Wheel Loader, which has exclusive comfort, ease of operation and maintenance, robustness, performance, and fully integrated components, giving a new meaning to the word productivity.

MAKE A QUOTE

TIPPING LOAD

8.953 kg

BUCKET CAPACITY

From 1.6 to 3 m³

Specifications

Standard Equipment

Enclosed cab ROPS/FOPS (ISO 3471, ISO 3449)
Air conditioning
Auxiliary front headlights
Two-speed front windshield wiper
Timer and water sprayer
Fabric seat with height and load adjustment, mechanical suspension, and recline function
Armrest
Seatbelt
Single control lever
Hydraulic steering
Adjustable tilt steering column
Knob control on the steering wheel
Internal and external rearview mirrors
F / N / R gear shifting

Four-wheel drive
Transmission with manual or automatic shift options, 4 forward speeds and 3 reverse speeds
Programmable electronic control module, computer-controlled proportional gear shifting with programmable speed selection
Onboard diagnostic system
Electronic gear shift control with a single lever
F/N/R shift on the loader control lever
Downshift button
Torque converter
External planetary axles
Differentials with limited-slip device
Transmission oil cooling system
Transmission disengagement via brake pedal actuation (Declutch)
Hydraulic wet disc brakes
Spring-applied, hydraulically released parking brake
Limp-Home mode

Single control for lift and tilt
Positive float lock
Automatic return-to-dig position
Automatic height control
Automatic return-to-carry position
Transmission disengagement via brake pedal (Declutch)

MAR I – Tier 3
Brand: FPT
Turbocharged diesel
Automatic alternator belt tensioner
Integrated cooling system
Hydraulically driven engine fan
Fuel filter with water separator
Dual-element air filter
120 A alternator
(2) 12 V batteries

20.5 x 25, 16-ply L3, three-piece 17” rim

Front and rear fenders
Front and rear turn signals with hazard lights
Counterweight
Tow pin
Articulation locking bar
Lift arm locking bar
Front/rear tie-down points
Reverse alarm
Remote drain points
Centralized lubrication points

(2) Front headlights (high/low beam)
(2) Cab work lights
(2) Rear tail/brake lights
(2) Rear work lights

Specifications

Optional

Quick coupler for attachments
Auxiliary hydraulic system for operating the quick coupler cylinder
Loader controls
Buckets (see page 5)

Auxiliary hydraulic system for quick coupler
Ride Control

3 or 4-function hydraulic valves, with control via:

3 or 4 levers
Joystick plus 1 or 2 levers

Componentes con bordes biselados y pintura especial para protección contra ambientes corrosivos
Aplicación de barniz especial en toda la superficie de la máquina para una protección adicional
Balde dimensionado para el manejo de fertilizantes
Chasis con aberturas para evitar la acumulación de material
Protección especial para terminales eléctricos
Tubos con tratamiento superficial adicional para mayor durabilidad
