2050M
The most power and performance in the CASE lineup and in its size class. The 2050M is the dozer you need for large cuts and mass earthmoving — and is fully compatible with an entire range of machine control/grade control solutions including the optional factory fit machine control. Match that with industry-leading visibility, a clean and comfortable operator station, and powerful settings to dial in machine performance for the heaviest work — and the 2050M wins in strength, controllability and precision.
DOWNLOADS
Download Brochures
Share or download a brochure for additional information.
Horsepower @2000 rpm SAEJ1349 - Net - Imperial
160 kW/ 214 hp
Horsepower @2000 rpm SAEJ1349 - Gross - Imperial
173 kW/ 232 hp
SPECIFICATIONS
Standard Equipment
- Fully enclosed ROPS cab
- Single lever control for speed, steering and direction
- Cloth air suspension seat w/ back adjustment
- Retractable 3 in (76 mm) seat belt
- Adjustable armrest
- Two foot rest
- Rearview mirror
- Two door windshield wipers
- Dome light
- 12-volt accessory outlet
- Headliner
- Floor mat
- Rear Wiper
- Radio
- Heat/AC
Warning lights
- Air filter
- Alternator
- Diagnostic fault indicator
- Engine coolant temperature
- Engine oil pressure
- Hydraulic filter
- Low fuel level
- DEF fluid level
- Park brake engaged
- Service soon indicator
- Transmission filte
- Transmission charge pressure
Gauges
- Battery voltage
- Fuel level
- Digital hour meter/tachometer/diagnostic/service reminder
- Transmission oil temperature
- Transmission speed indicator
- Water temperature
- Diesel Exhaust Fluid (DEF) level
Audible warnings
- Engine coolant temperature
- Engine oil pressure
- Low fuel level
- Transmission charge pressure
- Temperature/ hydraulic temperature
- FPT F4HE96848
- Tier 3 Final Certified
- Integral engine oil cooling
- Fuel filter
- Dual element radial seat air cleaner
- 120 amp alternator
- 2 x 12 V batteries
- Engine side panels
- Dual path infinitely variable, singlelever controlled Hydrostatic drive with Electronic Straight Tracking and
- Counter-rotation
- Forward/reverse ratio control
- 3 pre-selectable steering sensitivities
- 3 reversing sensitivities
- 3 blades sensitivities
- Blade Shaking Mode
- Fine grading mode
- Triple reduction nal drive: helical gear/planetary
- Decelerator with hydrostatic drive retardation
- Automatic spring applied parking brake
- 50°- 60° variable pitch with Integral
- Adjustment Tool, Single Lever,
- Electro-Hydraulic control for blade lift, angle, or tilt “Equistatic” device for dozer version
- Hydraulic track adjusters
- CASE Extended Life Track (CELT)
- Chain
- Permanently lubricated (track and carrier rollers/idlers)
- Track adjuster guard
- Track guides - front and rear
- Reverse gear warning
- Horn
- Work lights: 2 front, 1 rear
- Master disconnect switch
- Mirror
- Rear transmission guard
SPECIFICATIONS
Optional Equipment
- Cab with heat, A/C, defroster, lights
- Seat belt – 3 in (76 mm)
- Rear wiper for cab
- Radio
- 4 spool hydraulic valve for fieldinstalled ripper
- 3 spool hydraulic valve without plugs for field-installed ripper
- 3 spool hydraulic valve with plugs
- Ripper - 5 positions with 3 shanks
- Rear tow hook
- Rear drawbar
- CAB canopy brush guard
- Center rockguard
- Sweeps
- Cab rear screen
- Radiator brush screen
- Environmental drain
- Grid heater
- Additional work lights
- Front pull hook
- Rear view mirror
- Rear wiper for cab
SPECIFICATIONS
Compare Specifications
ENGINE | ||
Model | ||
Cylinders | ||
Displacement | ||
Fuel injection | ||
Fuel filter | ||
Air intake | ||
Cooling | ||
Engine speeds | ||
High idle - no load | ||
Rated - full load | ||
Low idle | ||
Horsepower @2000 rpm SAEJ1349 - Net - Imperial | ||
Horsepower @2000 rpm SAEJ1349 - Net - Metric | ||
Horsepower @2000 rpm SAEJ1349 - Gross - Imperial | ||
Horsepower @2000 rpm SAEJ1349 - Gross - Metric | ||
Max torque | ||
Engine lubrication Pump | ||
Pump operating angle ratings - Side-to-side | ||
Pump operating angle ratings - Fore and aft | ||
TRANSMISSION COOLING | ||
ELECTRICAL SYSTEM | ||
POWERTRAIN | ||
BLADE | ||
HYDRAULICS | ||
UNDERCARRIAGE | ||
TRACK AND SHOE OPTIONS | ||
TRACK ON GROUND | ||
RIPPER | ||
SERVICE CAPACITY | ||
