CX350B
Specifications
Standard Equipment
- Common rail engine Tier III European Standards
- Electronic control of the injection system
- Automatic engine pre-heating
- Automatic/manual engine return to idle
- Exhaust Gas Recirculator
- Emergency stop
- Electrical refuel pump with automatic stop
- Fuel filter with water separator
- Auto / Heavy / Super Power working modes
- Pump torque variable control
- Automatic Power boost control
- Swing brake control
- High performance “Super Fine” synthetic fiber hydraulic filter (high contamination catch)
- Hydraulic safety valves on boom and dipper
- 2 travel speeds with auto down shifting
- High visibilty cab with safety glass
- Adjustable et retractable armrest console with position memory
- Safety lever
- Self adjusting Air conditioning and heating system
- Cup holder
- High visibility side monitor display with automatic brightness
- Messages (function, temperature, safety, ...) on the display
- Integrated diagnostic system
- Working modes (Auto/Heavy/Super Power) combined with engine throttle
- Anti-theft device
- Hourmeter
- Selectable auxiliary hydraulic flow pre-settings
- RH front console with clock and cell phone holder
- High capacity shock absorbers on cab with 4 points fluid mountings
- Rain deflector
- Windscreen with lockable opening
- Windscreen washer and wiper
- Removable lower front windscreen with storage location in cab
- Glass cab roof window and slidding sun shade
- ISO control pattern low effort & short joysticks
- Adjustable sun visor
- Washable cab floor mat
- Rear view mirror and safety mirrors
- Storage compartments
- Integrated cool box
- 12V and 24V DC accessory sockets
- Hammer / Shear change selected from the cab
- Fore & aft adjustment of the whole seat & console
- Water proof connectors
- Double horn
- 2 working light on the cab
- Working light on the fuel tank
- Working light on the boom
- EMS (Extended Maintenance System) pins and bushings as Standard (up to1000 hours lubrication interval for attachment bushings except bucket)
- Low friction resin side shims on boom and dipper
- Sealed and lubricated tracks
- Track guides (1 guide & front)
- Large tool box
- Pre-disposal for the optional cab protection
- Operator seat
- Fully adjustable low frequency mechanical suspension seat including double acting hydraulic damper
- Weight adjustment
- Height / fore & aft adjustment
- Adjustable head rest
- Adjustable seat back angle with Fully flat seat reclining
- Adjustable arm rest
- Safety belt
Specifications
Optional Equipment
- Bucket/clamshell hydraulic circuit
- Hammer hydraulic circuit
- Hammer/shear hydraulic circuit
- Additional track guides
- Track width (600mm - 700mm - 800mm - 900mm depending on the version)
- Windscreen prtection
- Cab protection
- GPS (Global Positioning System) by satelite
- Centralized greasing system automatically actuated by an electrical grease pum
ENGINE | ||
Make | ||
Type | ||
Cylinders | ||
Bore/Stroke | ||
Displacement | ||
Fuel | ||
Fuel injection | ||
Fuel filter | ||
Cooling | ||
Horsepower EEC80/1269 | ||
Horsepower per SAE J1349 - Net | ||
Maximum torque 80/1269/EEC | ||
Maximum torque @ 1500 rpm - Net | ||
HYDRAULIC SYSTEM | ||
ELECTRICAL SYSTEM | ||
UNDERCARRIAGE | ||
CIRCUIT AND COMPONENT CAPACITIES | ||
